THUNDERBIRD – STRIP LIGHTING
Features
The Thunderbird is a high visibility tube light and a high powered LED array (Light Emitting Diode) in a 20mm acrylic enclosed tube with an IP20 rating. This light is suited to Industrial Applications, Visible Break Isolation Panel Lighting, Emergency Lighting, Switch Board Panels and General Electrical Enclosure Lighting. The Thunderbird is a LED array suitable for harsh conditions and sustains a long life. It has been designed to reject electrical interference that normally abounds in industrial environments and includes screw connection for electrical termination.
Typical Applications
Cabinet Lighting
Electrical Enclosures
Visible Break Isolators
Strip Lighting
Specifications
| Model: | PLITHU |
|---|---|
| Optical Characteristics | |
| Rated Wattage | 6W |
| Lumens | 600 |
| System Efficacy | 100Lm/W |
| Colour Temperature CCT | 5500K |
| CRI (Ra) | >80 |
| Reported L70 | >50,000 Hours |
| Lens Optic Type | 120° |
| Electrical Characteristics | |
| Input | DC 24V |
| Frequency | 50Hz |
| Power Factor | >0.80 |
| Total Harmonic Distortion | <20% |
| Environment | |
| IP Rating | IP20 |
| Impact Rating | IK07 |
| Operating Temperature | 0°C to 70°C |
| Product Material and Mounting | |
| Option 1 | Bracket Mount |
| Product Material | Polycarbonate |
| Lens / Optics Material | Transparent PC Lens |
| Dimensions and Weights | |
| Product Dimensions | 192 × 215 |
| Product Weight | 100g |
| Packaging Dimensions | 200 × 225 |
| Gross Weight | 100g |
| Warranty and Certifications | |
| Warranty | 2 Year Warranty |
| Certifications | CE / RoHS |
