PHOENIX CHALLENGER – HIGH-POWER FLOODLIGHTS
Features
The Phoenix Challenger is a stainless-steel Floodlight/Bulkhead suitable for a wide range of applications. It features a die-cast stainless steel body that can withstand temperatures from -40°C to 50°C standard and 0°C to 50°C in emergency mode. It is designed with 3CCT (5000K/4000K/3000K) and 3 modes of mounting (Spigot, Stirrup & U Bracket). The Phoenix Challenger is a superior fitting that is designed for dusty, hot and dry Australian mining conditions.
Typical Applications
Coal & Metalliferous Mine Process Plants
Quarries
Campsite Area Lighting
General Area Lighting
Car Parks
Conveyors
Pedestrian Access Road Ways
Stacker/Reclaimers
Stairwells
Tunnels
Walkways
Bulkheads
Specifications
| Model No. | PLICHA50 | PLICHA100 | PLICHA150 |
|---|---|---|---|
| Optical Characteristics | |||
| Rated Wattage | 50W | 100W | 150W |
| Lumens | 6750 | 13500 | 20250 |
| System Efficacy | 135 lm/W | ||
| Colour Temperature CCT | 3CCT | ||
| CRI (Ra) | >70 | ||
| Reported L70 | >50,000 Hours | ||
| Lens Optic Type | 15° × 60° | ||
| Electrical Characteristics | |||
| Input | 90–305VAC | ||
| Frequency | 50Hz | ||
| Power Factor | >0.95 / 230VAC | ||
| Total Harmonic Distortion | <15% | ||
| Environment | |||
| IP Rating | IP66 | ||
| Impact Rating | IK08 | ||
| Operating Temperature | -40°C to 50°C (0°C to 50°C w/ Emergency Battery) | ||
| Product Material and Mounting | |||
| Option 1 | Spigot Mount (For OD 27–38mm Pipe) | ||
| Option 2 | U Bracket (For Square Pole) | ||
| Option 3 | Stirrup Mount (For Ceiling/Wall) | ||
| Product Material | Die-cast 316 Stainless Steel | ||
| Lens / Optics Material | PC Lens | ||
| Dimensions & Weights | |||
| Product Dimensions | 432 × 350 × 84 | ||
| Product Weight | 19.0kg | ||
| Packaging Dimensions | 550 × 460 × 120 | ||
| Gross Weight | 20.0kg | ||
| Warranty and Certifications | |||
| Warranty | 5 Year Warranty | ||
| Certifications | SAA | ||
