HAWK 2 – HIGH-POWER FLOODLIGHTS

26 Mar

Features

The Hawk 2 is a high powered LED floodlight designed for Mining and Industrial applications. It features a superior high output and offers a unique optical design that virtually eliminates glare with minimal impact on performance.

Typical Applications

Mining
MIA (Mining Infrastructure Area)
Coal
Open Cuts
Metalliferous
Iron Ore
Industrial
Processing Plants
Materials Handling
Lithium Processing
Power Generation
Energy & Utilities
Water & Waste Water
Ports, Wharfs & Waterways
Chemical & Processing
Ports & Wharves
Airports
Car Parks
General Area Lighting
Container Terminals

Specifications



        Model
        PLIHVK400
        PLIHVK500
        PLIHVK600
        PLIHVK800
        PLIHVK1000
        PLIHVK1200


    Optical Characteristics

        Rated Wattage
        400W
        500W
        600W
        800W
        1000W
        1200W


        Lumens
        64000
        78000
        90000
        130000
        155000
        180000


        System Efficacy
        150–160 lm/W


        Colour Temperature CCT
        5700K (5000K / 4000K / 3000K)


        CRI (Ra)
        >70 (>80 / >90 Optional)


        Reported L70
        >50,000 Hours*


        Lens Optics Type
        15° / 30° / 45° / 60°

Electrical Characteristics

        Input
        200–277V / 347V / 480V (Optional)


        Frequency
        50Hz


        Power Factor
        >0.96


        Total Harmonic Distortion
        <20%

Environment

        IP Rating
        IP66


        Impact Rating
        IK10


        Operating Temperature
        -40°C to 50°C

Product Material and Mounting

        Option 1
        Trunnion Mount Bracket


        Product Material
        Powder-Coated Die Cast Aluminium


        Lens / Optics Material
        Polycarbonate Lens

Dimensions and Weights

        Product Dimensions (mm)
        592×509×423
        592×509×423
        592×509×423
        697×649×520
        697×649×520
        697×649×520


        Product Weight
        18.3kg
        18.7kg
        19.2kg
        27.5kg
        29.0kg
        30.0kg


        Packaging Dimensions
        615×600×175
        615×600×175
        615×600×175
        765×715×185
        765×715×185
        765×715×185


        Gross Weight
        20.3kg
        20.7kg
        21.2kg
        30.5kg
        32kg
        32kg

Warranty and Certifications

        Warranty
        5 Year Warranty


        Certifications
        CE / RoHS




Model	PLIHVK400	PLIHVK500	PLIHVK600	PLIHVK800	PLIHVK1000	PLIHVK1200
Optical Characteristics
Rated Wattage	400W	500W	600W	800W	1000W	1200W
Lumens	64000	78000	90000	130000	155000	180000
System Efficacy	150–160 lm/W
Colour Temperature CCT	5700K (5000K / 4000K / 3000K)
CRI (Ra)	>70 (>80 / >90 Optional)
Reported L70	>50,000 Hours*
Lens Optics Type	15° / 30° / 45° / 60°
Electrical Characteristics
Input	200–277V / 347V / 480V (Optional)
Frequency	50Hz
Power Factor	>0.96
Total Harmonic Distortion	<20%
Environment
IP Rating	IP66
Impact Rating	IK10
Operating Temperature	-40°C to 50°C
Product Material and Mounting
Option 1	Trunnion Mount Bracket
Product Material	Powder-Coated Die Cast Aluminium
Lens / Optics Material	Polycarbonate Lens
Dimensions and Weights
Product Dimensions (mm)	592×509×423	592×509×423	592×509×423	697×649×520	697×649×520	697×649×520
Product Weight	18.3kg	18.7kg	19.2kg	27.5kg	29.0kg	30.0kg
Packaging Dimensions	615×600×175	615×600×175	615×600×175	765×715×185	765×715×185	765×715×185
Gross Weight	20.3kg	20.7kg	21.2kg	30.5kg	32kg	32kg
Warranty and Certifications
Warranty	5 Year Warranty
Certifications	CE / RoHS

Download brochure

HAWK 2 - HIGH-POWER FLOODLIGHTS

Download Technical Files

LOG IN TO ACCESS ALL THE TECHNICAL FILES
