FALCON – LED BATTENS WEATHERPROOF
Features
The Falcon is a general purpose LED weatherproof luminaire comprising a high impact UV stabilized diffuser. It features a pour in place polyurethane gasket in conjunction with a secure and screw lockable stainless steel latch system making the Falcon a hardy and durable luminaire.
Typical Applications
Mining
MIA (Mining Infrastructure Area)
Coal
Open Cuts
Metalliferous
Iron Ore
Industrial
Processing Plants
Materials Handling
Lithium Processing
Power Generation
Energy & Utilities
Water & Waste Water
Ports, Wharfs & Waterways
Chemical & Processing
Specifications
| Model | PLIFAL20 | PLIFAL20 | PLIFAL40 | PLIFAL60 |
|---|---|---|---|---|
| Rated Wattage | 20W | 20W | 40W | 60W |
| Lumens | 2000 | 2000 | 4000 | 6000 |
| System Efficacy | 100 lm/W | |||
| Colour Temperature | 5000K (4000K / 3000K) | |||
| CRI (Ra) | >80 | |||
| Reported L70 | >50,000 Hours | |||
| Lens Optic Type | 120° | |||
| Electrical Characteristics | ||||
| Input | 220–240VAC | |||
| Frequency | 50Hz | |||
| Power Factor | >0.90 | |||
| Total Harmonic Distortion | <20% | |||
| Environment | ||||
| IP Rating | IP65 | |||
| Impact Rating | IK08 | |||
| Operating Temperature | -20°C to 40°C | |||
| Product Material and Mounting | ||||
| Option 1 | Surface Mount Clips | |||
| Product Material | PC Body, Steel Gear Tray | |||
| Lens / Optics Material | PC Lens | |||
| Dimensions and Weights | ||||
| Product Dimensions | 665×90×88 | 665×90×88 | 1265×90×88 | 1565×90×88 |
| Product Weight | 1.1kg | 2.0kg | 2.5kg | 3.2kg |
| Packaging Dimensions | 690×240×310 | 690×240×310 | 1315×240×310 | 1315×240×310 |
| Gross Weight (Ctn 10) | 13.2kg | 24.0kg | 30.0kg | 38.4kg |
| Warranty and Certifications | ||||
| Warranty | 5 Year Warranty | |||
| Certifications | SAA / CE / RoHS | |||
