APOLLO – SOLAR LED
Features
The Apollo is an all in one solar luminaire, featuring built in MPPT technology that tracks the maximum sun for a quick charge. The Apollo allows for 8-10 hours of full brightness after a full charge, or 36 hours in dimming mode. It also features a wide range of control system functions: switch on, dimming, colour temperature, timing, light control, motion sensor, working status display, energy saving analysis, fault report, GIS positioning and group function via it’s in built iSense Smart Control System.
Typical Applications
Urban and Rural Roads
Highways
Water Dikes
Bridges
Parks
Industrial Areas
City Squares
Residential Areas
Specifications
| Model | PLIAP010 | PLIAP020 | PLIAP030 | PLIAP040 | PLIAP050 | PLIAP060 |
|---|---|---|---|---|---|---|
| Optical Characteristics | ||||||
| Rated Wattage | 10W | 20W | 30W | 40W | 50W | 60W |
| Lumens | 1700 | 3200 | 4440 | 5600 | 6750 | 7800 |
| System Efficacy | 170Lm/W | 160Lm/W | 148Lm/W | 140Lm/W | 135Lm/W | 130Lm/W |
| Colour Temperature | 5000K / 4000K / 3000K | |||||
| CRI (Ra) | >70 | |||||
| Reported L70 | >50,000 Hours | |||||
| Lens Optic Type | 70° × 150° | |||||
| Solar Characteristics | ||||||
| Solar Panel | 30W | 75W | ||||
| Photovoltaic Panel | Monocrystalline Silicon Photovoltaic Panel | |||||
| Li-ion Battery | 12V / 13AH | 12V / 40AH | ||||
| Charging Time | 5–7 Hours | |||||
| Run Time (Full) | 10 Hours | 7.5 Hours | 6 Hours | |||
| Environment | ||||||
| IP Rating | IP65 | |||||
| Impact Rating | IK08 | |||||
| Operating Temperature | -30°C to 50°C | |||||
| Product Material | ||||||
| Option 1 | Adjustable Post Top Mount (60MM Spigot) | |||||
| Option 2 | Adjustable Side Entry Mount (60MM Spigot) | |||||
| Housing | Aluminium Housing | |||||
| Lens Cover | PC Lens | |||||
| Dimensions and Weights | ||||||
| Product Dimensions | 649×366×128 | 931×535×137 | ||||
| Product Weight | 7.6KG | 16.4KG | ||||
| Packaging Dimensions | 644×434×188 | 980×600×180 | ||||
| Gross Weight | 8.4KG | 18.0KG | ||||
| Warranty & Certifications | ||||||
| Warranty | 3 Year Warranty | |||||
| Certification | SAA / CE | |||||
