CHANGEOVER PANELS
RELIABLE AC & DC POWER TRANSFER SOLUTIONS ISO CONNECT
FOR HARSH AUSTRALIAN CONDITIONS
Phoenix EMS Changeover Enclosures provide dependable and safe power source selection for industrial, commercial, and infrastructure applications.
Engineered for mining, oil & gas, materials-handling, and heavy-industry, these enclosures allow seamless switching between mains, generator, or backup supply — ensuring continuous operation even in the most demanding environments.
KEY FEATURES
AC & DC Operation
Configurable for alternating or direct current systems — ideal for hybrid, solar, and industrial power networks
IP66 Environmental Protection
Fully sealed against dust and water ingress, suitable for outdoor and wash-down installations.
Visual Isolation Window*
Clear viewing panel allows direct inspection of contact position for safe verification before maintenance or changeover.
Durable Construction
Available in Phoenix EMS mild-steel, stainless-steel, or powder-coated finishes, built to withstand corrosion, vibration, and impact.
Smooth, Reliable Switching
Positive-break changeover mechanism with clearly defined I–O–II positions for fast and secure source transfer.
Custom-Built Configurations
Options for 3- or 4-pole operation, handle orientation, cable entry layout, and gland plate configuration to suit any installation.
Applications
Mining and mineral-processing facilities
Oil & gas production and on-site power systems
Materials-handling and conveyor networks
Remote power generation and hybrid systems
Utilities, water treatment, and critical infrastructure
Industrial and commercial power distribution
The below are general specifications as all units are custom.
| Specification | Detail |
|---|---|
| Type | Manual Changeover Enclosure |
| Rated Current | 16 A - 1600 A (higher on request) |
| Rated Voltage | up to 1000 V AC / 1500 V DC |
| Poles | 3 / 4 Pole |
| Operating Positions | I - O - II |
| Enclosure Rating | IP66 |
| Visual Isolation Window | Included as standard * |
| Material Options | Mild Steel, Stainless Steel, or Custom Coated |
| Mounting | Wall, floor, or skid-mounted |
| Operating Temperature | -25 °C to +55 °C |
