GTS SERIES SKID BASE 1800
The GTS-1800-SKD-9H Mobile Solar Trailer from Green-Tek Solutions is a versatile alternative for emergency lighting, surveillance, and telecom needs, harnessing clean energy with its 6 solar panels while offering an optional 7-9m telescopic mast and compliance with Australian standards, making it easy to deploy, fuel-free, and silent in operation. Its portable design enables rapid response in disaster zones, providing sustainable power without emissions or noise, suitable for diverse applications including emergency response, remote operations, and temporary installations.
TYPICAL APPLICATIONS
Mining, Civil & Construction, Rail, Power Generation & Utilities, Road/Cycleways/Walking Paths, Security & Surveillance Municipal Councils & Events
FEATURES
GTS-1800-SKID DIMENSIONS
| SPECIFICATIONS | |||
|---|---|---|---|
| Model | GTS-1800-SKID | Rated Power | |
| Input Voltage | |||
| BASE | |||
| Material | Steel Q235 | Charging Efficiency | |
| Powder | Anti Corrosion Powder | Charging Circuit | |
| Dimension | Length × Width × Height | Charging Time | |
| Transporting | 2200×1100×2175 (mm) | Plug & Socket | |
| Operating | 3100×3100×9000 (mm) | ||
| Weight | 1650kg | ||
| System Voltage | DC48V | ||
| Work Temperature | -35°C ~ 50°C | ||
| SOLAR | BATTERIES | ||
| Solar Panel | 4 × 435W Monocrystalline Panels (Electric Lifting) | GEL | 8 × 200Ah |
| Voltage | 39V | Voltage | DC48V |
| Charging Time | 9 hours Solar | Series & Parallel | 4 in series |
| Power Capacity | |||
| LAMP | CONTROL | ||
| LED | 4 × 150W Module Outdoor Type, Smart-Lighting, Dimable | Solar Controller | MPPT 60A |
| Protection Class | IP65 | Efficiency | 95%+ |
| Lumens | 120000Lm | Detection & Protection | Short-Circuit, Overload, High Voltage, High Temperature |
| Beam Angle | Timer | Dusk & Dawn | |
| Voltage | DC48V | Whole Machine | Battery Isolator, Light on-off, Mast / Panel up-down, Rotation & Tilt |
| Running Time | 22 hours | ||
| MAST | TRAILER SYSTEM | ||
| Body | Galvanized Steel Q235 | Standard | US / AU / EU |
| Fastener | Stainless steel 304 | Forklift Hole | 2 |
| Wire Rope | Stainless steel 316 | Outrigger | 4 × Manual, Galvanized |
| Type | Square Telescopic | Warranty | 2 years |
| Height | 9m | ||
| Section | 9 | ||
| Rotation | 360° Electric | ||
| Tilt | 90° Electric | ||
| Spring Cable | Power Supply | ||
| Lifting Method | Hydraulic | ||
| Recommended Loading | 100kg | ||
| Windproof | 117km/h | ||
| ACCESSORIES | |||
| Operation Manual | Parts Manual | ||
| Controller Manual | Allen Wrench, Hex Wrench | ||
| CERTIFICATION | |||
| ISO14001, ISO9001, OHSAS 18001, CE, SAA, UL | |||
