EXCALIBUR FILTER FANS PVA500BPB, PVA524BPB
Features
• Voltage: 240VAC and 24VDC options.
• Quick and simple mounting for hassle-free installation.
• Cabinet Ventilation: Tailored for ventilating control cabinets and enclosures.
• Space-Saving: Compact size with small external dimensions
• Versatile Mounting: Compatible with various setups
• RAL7035
• IP Rating: IP54
Filter And Fan Unit Specifications
| Model No. | PVA500BPB | PVA524BPB |
|---|---|---|
| Rated operating voltage V | 220V-240VAC | 24VDC |
| Frequency Hz | 50/60 | - |
| Air throughput, unimpeded air flow | 35m³/h | 35m³/h |
| Air throughput with Exit filter including standard filter mat | 24/27m³/h | 24/27m³/h |
| Axial fan | Self-starting shaded pole motor | DC motor |
| Rated current max. | 0.08–0.07A | 0.4A |
| Rated Power | 13W | 9.6W DC |
| Noise level | 35dB(A) | 35dB(A) |
| Operating temperature range | -30°C to +70°C | -30°C to +70°C |
| Model No. Exit filter | PVA000BPB | |
| Material | Made of injection-moulded thermoplastic, customizable flame retardant material (UL94-40) | |
| Air flow direction | Air-in as default; air-out optional | |
| Protection Level | IP54 | |
