GTS 600 SKID
The GTS-600-SKiD Mobile Solar skid from Green-Tek Solutions is a versatile alternative for emergency lighting, surveillance, and telecom needs, harnessing clean energy with its 6 solar panels while offering an optional 7-9m telescopic mast and compliance with Australian standards, making it easy to deploy, fuel-free, and silent in operation. Its portable design enables rapid response in disaster zones, providing sustainable power without emissions or noise, suitable for diverse applications including emergency response, remote operations, and temporary installations.
TYPICAL APPLICATIONS
Mining, Civil & Construction, Rail, Power Generation & Utilities, Road/Cycleways/Walking Paths, Security & Surveillance Municipal Councils & Events
SPECIFICATIONS
| SPECIFICATIONS | |||
|---|---|---|---|
| Model | GTS-600-SKID | Input Voltage | AC220V |
| BASE | |||
| Material | Steel Q235 | Charging Efficiency | |
| Powder | Anti Corrosion Powder | Charging Circuit | |
| Dimension | Length × Width × Height | Charging Time | 4.9 hours AC |
| Transporting | 2900×1500×2500 (mm) | Plug & Socket | 1 × AC240V |
| Operating | 2900×2500×6200 (mm) | ||
| Weight | 1000kg | ||
| System Voltage | DC24V | ||
| Work Temperature | -20° ~ 50°C | ||
| SOLAR | BATTERIES | ||
| Solar Panel | 2 × 445W Monocrystalline Silicon | LFP | 1 × 314Ah |
| Voltage | Voltage | DC25.6V | |
| Charging Time | 9.3 hours Solar | Series & Parallel | |
| Power Capacity | 8038Wh | ||
| LAMP | CONTROL | ||
| LED | 2 × 150W Module Outdoor Type, Smart-Lighting, Dimmable | Solar Controller | MPPT 40A |
| Protection Class | IP67 | Efficiency | 95%+ |
| Lumens | 68000Lm | Detection & Protection | Short-Circuit, Overload, High Voltage, High Temperature |
| Beam Angle | Timer | Dusk & Dawn | |
| Voltage | DC24V | Whole Machine | Battery Isolator, Light on-off, Mast/Panel up-down, Rotation & Tilt |
| Running Time | 38.4 hours | ||
| MAST | TRAILER SYSTEM | ||
| Body | Galvanized Steel Q235 | Standard | US / AU / EU |
| Fastener | Stainless Steel 304 | Forklift Hole | 2 |
| Wire Rope | Stainless Steel 316 5mm | Outrigger | 4 × Manual, Galvanized |
| Type | Square Telescopic | Warranty | 2 years |
| Height | 6.5m | ||
| Section | 5 | ||
| Rotation | 360° Electric | ||
| Tilt | 90° Electric | ||
| Spring Cable | Power Supply | ||
| Lifting Method | Manual Winch | ||
| Recommended Loading | 70kg | ||
| Windproof | 117km/h | ||
| CHARGER | ACCESSORIES | ||
| Rated Power | 2.5kW / 2.5kVA | Operation Manual | Parts Manual |
| Controller Manual | Allen Wrench, Hex Wrench | ||
| CERTIFICATION | |||
| ISO14001, ISO9001, OHSAS 18001, CE, SAA, UL | |||
Download brochure
GTS 600 SKID (Pdf)
